DH type all steel platform digital truck scale is a new generation truck scale of Quanzhou Dahua Electronic Weighing Instrument Co., Ltd. It adopts U-shaped steel structure, with good overall structure, strong steel property, good technology, and is not easy to deform in case of transverse force. The scale platform design is modularized, standardized and serialized. Can be freely combined into a variety of specifications. The truck scale uses high-precision stainless steel sensor and intelligent weighing display instrument. The system has superior measuring performance, high accuracy, long-term stability and convenient installation and maintenance. It is widely used in port, factory, goods yard, storage terminal, workshop, warehouse and other occasions for incoming and outgoing materials, inventory measurement, production monitoring and data management. It is suitable for weighing calculation of all kinds of trucks, trailers, semi trailers, containers and other vehicles. Weighing display has the functions of automatic zero setting, storage of vehicle tare weight, overload alarm, etc. External printer can print date, car number, article number, gross weight, net weight and other data after weighing. It can be accumulated according to the weighing results and print the accumulated report.

Unique box structure of bridge

                          . The product has the following characteristics:

    1. In the shape of the member, the span of the middle plate of the cross-section (vertical reinforcement plate) and the middle fulcrum of the longitudinal section have the greatest influence on the steel property. In view of this, the company has 8-10 main beams (designed according to tonnage and table size) for each weighing platform, so as to ensure the overall rigidity of the weighing platform.

   2. The company introduces special forming equipment (large-scale double machine linked bending machine). Adopt straight section assembly welding. The components are made of special equipment, with good overall structure and strong steel property. This is why the steeliness of the platform is stronger. The inner chamber of the weighing platform is fully sealed, which is not easy to rust. After shot blasting, the steel plate adopts epoxy zinc rich primer and acrylic marine paint. The oil film is thick and the thickness is 110 microns. It is wear-resistant, pressure resistant, acid, alkali resistant and corrosion-resistant.

    3. Modularization: it is made into 6m / 8m / 10m / three modules, which can be combined at will according to the different table size to ensure the consistency of products, which is conducive to production organization arrangement and on-site installation and commissioning.

Product parameters:

Accuracy level: OIML (LI)

Weighing scale: 10-150 (T)

Platform length: 5-24m

Scale platform degree: 2.5-3.4m

Temperature range: similar to table: - 100 C to + 40c

Scale body: - 300 C to 65 * C

Relative temperature: < 95%

Working voltage application: voltage application: 220V (AC)

Frequency: 50Hz

Fractional degree: z5kg

Technical training:

All our customers are free of charge to enjoy value-added services such as the training of weighbridge use, the training of maintenance skills for common problems, and the training of spare parts maintenance knowledge.

There are two options for platform size of Weighbridge

1. Purchase according to the table size specified by the company; 2. Make to order according to the size specified by the customer.

Order processing commitment:

After signing the contract and receiving the deposit, organize production within 3 days and deliver within one week.

payment method:

30% of the reservation fee, 60% of the lifting fee, and 10% of the installation and commissioning fee.

after-sale service:

This product is approved for production by the provincial technical supervision department. Product quality assurance for one year, life-long technical services.

24-hour remote hotline technical help;

Within 48 hours, the technical engineer shall remove the fault on site.
